Description
The bottle cleaning machine is consists of stainless steel water pump,high pressure nozzle, electrical box and other components.It is applicable to the special cleaning equipment such as glass bottle and plastic bottle brush cleaning and water flushing cleaning alone or in combination.
High-pressure jet backwash is used to make the debris in the bottle wall fall off into the tank in time.
Highlight:
Model
Bottle cleaning machine
Bottle type
50-1000ml(can be customized)
Production capacity
10-200 bottles per minute
Power supply
1 phase,220V 60/50Hz or 3 phase 380V(Can be customized)
Weight
800KG
Total dimension
2150 * 1150 * 2050mm(Can be customized)
1.The chuck adopts the groove design, the bottle moves when the stability does not shift.
2.Adopt strong elastic bottle clamp, grasp the bottle firmly and not hurt the bottle.
3.Machine is made of stainless steel 304,completely meets GMP standard.
4.Simple transmission system:adopt unitary type platen,has good stainless steel structure,easy to washing and cleaning, the whole machine transmission adopt suspension type block bottle neck system .transmission system has large space ,easy to maintain. Adopt centralization lubrication system, easy to take good care of the machine.
5.Easy to change bottle type:change parts are all adopt open structure, change the bottle type quickly and easy, suitable for most kinds of bottles.
